SIMULIA | Abaqus Unified FEA Solution
Discover the most powerful suite of realistic product simulation.
SIMULIA | Abaqus Unified FEA Solution
In the race to deliver innovative new products to market, manufacturers face many challenges including globalization, shrinking budgets, and shorter development cycles. To gain a competitive advantage in the marketplace, manufacturers have started to leverage the robust capabilities of realistic simulation to lessen dependency on physical testing, increase product reliability, and reduce time to market.
The SIMULIA Abaqus Unified FEA product suite offers a complete solution for realistic structural simulation covering both routine and advanced workflows across the range of industrial applications. Best-in-class companies are taking advantage of Abaqus Unified FEA to consolidate their tools, reduce costs, increase efficiency, and gain a competitive advantage.
We are a trusted reseller of SIMULIA Abaqus in India, a proud Dassault Systèmes Partner. We offer the complete suite of Abaqus software solutions. Our expertise ensures you get the right Abaqus software for your needs.
Contact today for best ABAQUS Software Price INDIA!
ABAQUS / CAE
COMPLETE SOLUTION FOR ABAQUS FINITE ELEMENT MODELING, VISUALIZATION, AND PROCESS AUTOMATION
With Abaqus/CAE you can quickly and efficiently create, edit, monitor, diagnose, and visualize advanced Abaqus analyses. The intuitive interface integrates modeling, analysis, job management, and results visualization in a consistent, easy-to-use environment that is simple to learn for new users, yet highly productive for experienced users. Abaqus/CAE supports familiar interactive computer-aided engineering concepts such as feature-based, parametric modeling, interactive and scripted operation, and GUI customization.
Users can create geometry, import CAD models for meshing, or integrate geometry-based meshes that do not have associated CAD geometry. Associative Interfaces for CATIA V5, SolidWorks, and Pro/ENGINEER enable synchronization of CAD and CAE assemblies and enable rapid model updates with no loss of user-defined analysis features.
The open customization tool set of Abaqus/CAE provides a powerful process automation solution, enabling specialists to deploy proven workflows across the engineering enterprise. Abaqus/CAE also offers comprehensive visualization options, which enable users to interpret and communicate the results of any Abaqus analysis.
Users can create geometry, import CAD models for meshing, or integrate geometry-based meshes that do not have associated CAD geometry. Associative Interfaces for CATIA V5, SolidWorks, and Pro/ENGINEER enable synchronization of CAD and CAE assemblies and enable rapid model updates with no loss of user-defined analysis features.
The open customization tool set of Abaqus/CAE provides a powerful process automation solution, enabling specialists to deploy proven workflows across the engineering enterprise. Abaqus/CAE also offers comprehensive visualization options, which enable users to interpret and communicate the results of any Abaqus analysis.
ABAQUS / STANDARD
SOLUTION TECHNOLOGY FOR STATIC AND LOW-SPEED DYNAMIC EVENT
Abaqus/Standard employs solution technology ideal for static and low-speed dynamic events where highly accurate stress solutions are critically important. Examples include sealing pressure in a gasket joint, steady-state rolling of a tire, or crack propagation in a composite airplane fuselage. Within a single simulation, it is possible to analyze a model both in the time and frequency domain. For example, one may start by performing a nonlinear engine cover mounting analysis including sophisticated gasket mechanics. Following the mounting analysis, the pre-stressed natural frequencies of the cover can be extracted, or the frequency domain mechanical and acoustic response of the pre-stressed cover to engine induced vibrations can be examined. Abaqus/Standard is supported within the Abaqus/CAE modeling environment for all common pre- and post processing needs.
The results at any point within an Abaqus/Standard run can be used as the starting conditions for continuation in Abaqus/Explicit. Similarly, an analysis that starts in Abaqus/Explicit can be continued in Abaqus/Standard. The flexibility provided by this integration allows Abaqus/Standard to be applied to those portions of the analysis that are well-suited to an implicit solution technique, such as static, low-speed dynamic, or steady-state transport analyses; while Abaqus/Explicit may be applied to those portions of the analysis where high-speed, nonlinear, transient response dominates the solution.
The results at any point within an Abaqus/Standard run can be used as the starting conditions for continuation in Abaqus/Explicit. Similarly, an analysis that starts in Abaqus/Explicit can be continued in Abaqus/Standard. The flexibility provided by this integration allows Abaqus/Standard to be applied to those portions of the analysis that are well-suited to an implicit solution technique, such as static, low-speed dynamic, or steady-state transport analyses; while Abaqus/Explicit may be applied to those portions of the analysis where high-speed, nonlinear, transient response dominates the solution.
ABAQUS / EXPLICIT
COMPLETE SOLUTIONS FOR REALISTIC SIMULATION
Abaqus/Explicit is a finite element analysis product that is particularly well-suited to simulate brief transient dynamic events such as consumer electronics drop testing, automotive crashworthiness, and ballistic impact. The ability of Abaqus/Explicit to effectively handle severely nonlinear behavior such as contact makes it very attractive for the simulation of many quasi-static events, such as rolling of hot metal and slow crushing of energy absorbing devices. Abaqus/Explicit is designed for production environments, so ease of use, reliability, and efficiency are key ingredients in its architecture. Abaqus/Explicit is supported within the Abaqus/CAE modeling environment for all common pre- and post processing needs.
The results at any point within an Abaqus/Explicit run can be used as the starting conditions for continuation in Abaqus/Standard. Similarly, an analysis that starts in Abaqus/Standard can be continued in Abaqus/Explicit. The flexibility provided by this integration allows Abaqus/Explicit to be applied to those portions of the analysis where high-speed, nonlinear, transient response dominates the solution; while Abaqus/Standard can be applied to those portions of the analysis that are well-suited to an implicit solution technique, such as static, low-speed dynamic, or steady-state transport analyses.
The results at any point within an Abaqus/Explicit run can be used as the starting conditions for continuation in Abaqus/Standard. Similarly, an analysis that starts in Abaqus/Standard can be continued in Abaqus/Explicit. The flexibility provided by this integration allows Abaqus/Explicit to be applied to those portions of the analysis where high-speed, nonlinear, transient response dominates the solution; while Abaqus/Standard can be applied to those portions of the analysis that are well-suited to an implicit solution technique, such as static, low-speed dynamic, or steady-state transport analyses.
ABAQUS MULTIPHYSICS
COMPLETE SOLUTIONS FOR REALISTIC SIMULATION
The Abaqus Unified FEA product suite has significant capabilities that are used to solve multiphysics problems. These capabilities, developed over many years and fully integrated as core Abaqus functionality, have been used extensively for many engineering applications on products and engineering projects in use today.
Multiphysics technology has been a part of Abaqus from the beginning. Starting with Abaqus V2 (in 1979), Abaqus/Aqua simulates hydrodynamic wave loading on flexible structures for offshore pipelines. Through the years additional multiphysics capabilities have been added, such as fluid, thermal, and electrical couplings, to name a few.
The advantage of Abaqus Multiphysics is the ease with which Multiphysics problems can be solved by the Abaqus structural FEA user. From the same model, same element library, same material data, and same load history, an Abaqus structural FEA model can easily be extended to include additional physics interaction. No additional tools, interfaces, or simulation methodology are needed.
Multiphysics Capabilities in Abaqus:
Multiphysics technology has been a part of Abaqus from the beginning. Starting with Abaqus V2 (in 1979), Abaqus/Aqua simulates hydrodynamic wave loading on flexible structures for offshore pipelines. Through the years additional multiphysics capabilities have been added, such as fluid, thermal, and electrical couplings, to name a few.
The advantage of Abaqus Multiphysics is the ease with which Multiphysics problems can be solved by the Abaqus structural FEA user. From the same model, same element library, same material data, and same load history, an Abaqus structural FEA model can easily be extended to include additional physics interaction. No additional tools, interfaces, or simulation methodology are needed.
Multiphysics Capabilities in Abaqus:
The Abaqus Unified FEA product suite has significant capabilities that are used to solve multiphysics problems. These capabilities, developed over many years and fully integrated as core Abaqus functionality, have been used extensively for many engineering applications on products and engineering projects in use today.
Multiphysics technology has been a part of Abaqus from the beginning. Starting with Abaqus V2 (in 1979), Abaqus/Aqua simulates hydrodynamic wave loading on flexible structures for offshore pipelines. Through the years additional multiphysics capabilities have been added, such as fluid, thermal, and electrical couplings, to name a few.
The advantage of Abaqus Multiphysics is the ease with which Multiphysics problems can be solved by the Abaqus structural FEA user. From the same model, same element library, same material data, and same load history, an Abaqus structural FEA model can easily be extended to include additional physics interaction. No additional tools, interfaces, or simulation methodology are needed.
Multiphysics technology has been a part of Abaqus from the beginning. Starting with Abaqus V2 (in 1979), Abaqus/Aqua simulates hydrodynamic wave loading on flexible structures for offshore pipelines. Through the years additional multiphysics capabilities have been added, such as fluid, thermal, and electrical couplings, to name a few.
The advantage of Abaqus Multiphysics is the ease with which Multiphysics problems can be solved by the Abaqus structural FEA user. From the same model, same element library, same material data, and same load history, an Abaqus structural FEA model can easily be extended to include additional physics interaction. No additional tools, interfaces, or simulation methodology are needed.
Multiphysics Capabilities in Abaqus:
- Coupled Eulerian-Lagrangian
- Piezoelectric-Mechanical
- Thermal-Electric
- Thermal-Fluid-Mechanical
- Hydrostatic-Fluid-Mechanical
- Structural-Acoustic
- Thermal-Mechanical
- Structural-Pore Pressure
SIMULIA Abaqus Unified FEA Solution Key Benifits
FEA and Multiphysics
- Linear and nonlinear
- Coupled physics: structural acoustics, thermal-electrical, and more
- Electromagnetics and smoothed particle hydrodynamics
Complex Assemblies
- Flexible multibody dynamics, controls, and joint behavior
High-Performance Computing
- Scaling from 4 to 256 cores for rapid turnaround and large-scale analyses
Complex Materials
- Rubbers, thermo-plastics, powder metals, human tissue, soil, composites, and more
Contact, Fracture & Failure
- Crack, impact, and crash events
Model Preparation and Results Interpretation
- Automation tools for customization of standard workflows
1. Are you authorized reseller of SIMULIA Abaqus Software India?
Yes, we are authorized partner with Dassault Systemes for Sale, service and training of SIMULIA Abaqus in India. Concepita Konnect is also one of the largest reseller of SOLIDWORKS suite of products in India.
2. What are the different Abaqus licensing options available?
Abaqus licensing options depends on different usage requirements. Commercial license types are Node locked, Floating, Term and Perpetual licenses. Furthermore, SAAS cloud connected solutions are also available depends on the type of analysis. Connect with us to know more.
3. How well does Abaqus integrate with our existing CAD software (e.g., SolidWorks, CATIA, Creo)?
Connector for SOLIDWORKS CAD and CATIA is available to directly transfer CAD geometry from CAD interface to Abaqus. However, neutral file formats can also be imported directly to Abaqus without any CAD connectors.
4. What kind of technical support and training does Dassault Systèmes (or its resellers) offer for Abaqus users?
Our certified support specialist at Conceptia Konnect provide online and offline support to troubleshoot issues related to SIMULIA Abaqus. Instructor led offline/online training is offered to customers.
